Module sans fil 5G WiFi Module MT7612E Carte sans fil Gigabit double bande Linux System Development Mod - Générique

Features: 1. Comply with 802.11ac standard, support 5.8Ghz, 867Mbps;
2. Supports 802.11i security standard; MT7612E wireless WiFi module, WiFi5 standard/stable connection/fast transmission speed
3. Support hardware accelerator TKIP.CCMP, GCMP, WAPI; high-efficiency 802.11ac solution, flexible combination of 5G single-frequency FEM adaptation test
4. Built-in PA and LAN design; supports wide coverage and indoor and outdoor applications;
5. Supports 802.11e video, voice and multimedia applications; supports Linux system/Android system, please note! Does not support systems
Description:
Chip: MT7612E
1.Network: IEEE 802.11a/b/g/ac
2.External PA: SKY85712-21
3. Interface type: Goldfinger PCle interface
4. Working voltage: 3V@1A, 5V@1A
5.Average power consumption: less than 3W
6. Working temperature: 0~+55
7. Working humidity: 5%~95%RH (non-condensing)
8. Storage temperature: -40~+90
9. Storage humidity: less than 90%RH (non-condensing)
Note: Depending on the batch, the appearance, color, and printing of the product , which does not affect use.
Material: PCB
colour: As shown
Package Contents:
1 x Wireless Module
Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
