4 Port Poe Injecteur Poe Adaptateur Secteur Ethernet Broche d¿alimentation 4,5 (+) / 7,8 (-) Entrée Dc12V-DC48V pour - Générique

4 Port Poe Injecteur Poe Adaptateur Secteur Ethernet Broche d¿alimentation 4,5 (+) / 7,8 (-) Entrée Dc12V-DC48V pour It does not have auto detection function and directly supply power to devices by force as as you connect ,powered device or poe splitter must conform to standard IEEE 802.3af/at,the same time your powered device must support poe pin 4/5(+),7/8(-)midspan.Power Input = Power Output*channels,Take 4Port POE,injector as example:DC48V 4A Input = DC12 V1A Output per channel,DC48V 2A Input = DC48V 0.5A output per channel.If you only use 3 of 4 channels,DC12V3 A input = DC12V 1A output per channel. select according your device power consumption,in order to stable running,the power consumption must be lower than the power supply.This POE adapter apply for IEEE802.3af/at standard POE powered devices like , and other IP cameras,or being equipped with IEEE802.3af/802.3at standard poe splitter for non POE devices.Led:Indicate the working state,Lan port:8ports in RJ45(data in),8port poe RJ45(data&power out),Data in:PC/Hub/Switch/Router,etc.Working temp:0~+40 Celsius.Working humidity:20 ~90% RH non-condensing,Storage temp & humidity:-20~+85 Celsius,10~95% RH,weight:120gColour:Black Material:ABS + electronic componentsProduct size:10*4.7*3.1cmPackage Contents:1 * 4 port POE hub1 * cartonOnly the above package content, other products are not included.Note: Light and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
